NANOBASE Transmission VPH Grating Options

Enhance the versatility and performance of your XperRAM series Raman spectrometers with our advanced Transmission VPH Grating options. Designed for quick and precise interchange, these gratings allow you to tailor the spectral range and resolution to match your specific experimental needs. With a wide selection of grating specifications, you can optimize your system for various laser wavelengths, achieving superior spectral accuracy and sensitivity.

Optimized Transmission Grating for Peak Efficiency

SpectraBoost (9).png

Easy Grating Replacement

SpectraBoost (10).png

Grating Options for XperRAM-C-WR

VPH Grating (3).png

Grating Options for XperRAM-C-HR

VPH Grating (4).png

Grating Options for XperRAM-S-WR

VPH Grating (5).png

Grating Options for XperRAM-S-HR

VPH Grating (6).png

Grating Options for XperRAM-S-NIR

VPH Grating (7).png

How to Replace Grating in XperRAM Series

Insert a new grating

Set system configuration

Adjustment of grating angle

VPH Grating (8).png

We provide optimized VPH Grating options for your experimental goals, sample characteristics, applications, wavelength and resolution requirements. Contact our technical sales team.
